Product Description

Steel structure building is a new type of structure building system. The main steel frame is formed by connecting H-beams, Z-beams, and U-beams on the roof and walls by various panels.The steel structure building is sturdy and durable and can with stand high winds, snow, or earthquakes. Our structural engineers design the building structure according to the local wind and snow load to ensure that the entire building can withstand the harsh external weather. The steel structure is installed quickly, and the construction time is short. All steel components were processed in the workshop, cut, welded, drilled, sandblasted, and painted, and delivered to the project site for installation. It does not cause environmental pollution at the installation site.

Product Parameters

The basic components of light steel structure	1. Main rigid frame: composed of columns and beams;If there is a crane, a crane girder is also included.A, common materials: Q235, Q355;B. Common cross-sectional forms of beams and columns: H-shaped steel, trusses (beams are mostly used), lattice columns;C. Common structural forms: portal rigid frame, frame structure;2. Support system: including tie rods, horizontal supports, inter-column supports, and corner supports.A. Tie rods are usually used: steel pipes, rectangular pipes;H-beam, channel steel, C-beam, angle iron and so on can also be used;B. The inter-column support is usually used: round steel, steel pipe, angle iron;H-beam, channel steel, I-beam, etc. can also be used;C. Angle braces are usually used: angle iron;3. Enclosure system: including purlins, purlins rods, roof panels, wall panels, doors, windows, lighting panels, and gas floors.A. Purlin: mainly used, C-shaped steel and Z-shaped steel are cold-formed with hot-drawn steel plate and hot-rolled galvanized steel plate.B. Wall and roof color plates: mainly using high-strength, cold-rolled color steel plates, galvanized or aluminum-zinc color steel plates, stainless steel plates, aluminum alloy plates, and titanium alloy plates.Commonly used in China is galvanized or aluminum-zinc color steel plate.
Material classification	1. According to the composition of the material: ordinary carbon steel (Q235) and ordinary low-alloy steel (Q355, Q390, Q420);Ordinary low-alloy steel is the addition of one or several alloying elements on the basis of ordinary carbon steel.2. According to the intensity: Q235, Q355, Q390, Q420;Among them, Q235 and Q355 are commonly used materials.
Basic data for the design(depand on the project need)	1. Dead load: must be provided2. Live load: must be provided3. Wind load: must be provided4. Snow load: required in areas with snow5. Ash load: it needs to be provided in dusty places (such as deserts and cement plants)6. Crane load: lifting weight, number of cranes.7. Seismic load: must be provided
The component connection method of the steel structure	1. Welding connection2. High-strength bolt connection3. Rivet connection
Anti-corrosion method of steel components (commonly used)	1. Galvanizing:2. Spray anticorrosive paint: red dan, iron red, epoxy zinc-rich paint;
Advantages of steel structure	a) High strength; b) Good reliability; c) Easy to construct.
Features of lightweight steel structure	Lightweight, accurate, convenient and fast molding, convenient for industrial production and transportation, construction and installation are more convenient, short construction period and low cost.

BingFa prefab house Co., Ltd. is a professional manufacturer of prefabricated houses, container houses, light steel villas, steel structures and sandwich panels. Our factory is located in Foshan, China, the famous Pearl River Delta region in southern China, and is closely connected with highway, railway and port facilities. Within 10 years, our prefabricated houses, steel structures and sandwich panels have occupied a certain market share, and have been highly praised by domestic and foreign customers. Our products are widely used in construction site offices, labor camps, workers accommodation, canteens, laboratory buildings, storage rooms, warehouses, workshops, kitchens, lounges, toilets, taverns, etc. The annual output of the product is as follows: Steel structure-10,000 tons ,container house-6000 units,prefabricated house-360,000 square meters, light steel villa-200,000 square meters, sandwich panel-2,000,000 square meters. We always enhance our application abilities of prefab house and promote the new-green type house under the work of our strong techical team,strict QC team,talent R&D team,rich experienced Sales Team,skilled production team. Basing on their good management,strict qulitity control and excellent service,we success to export our products to Australia,Middle East,Asia,Africa,South America etc.

Production process

Packaging & Shipping

Loading: We have a professional loading team and cranes, which can complete the loading quickly and meticulously.We have strict enforcement standards when it comes to protecting our products.

Certifications

FAQ
